PT-80 Delay
This is my PT-80 delay the information for this build can be found on generalguitargadgets.com.
I used acid graphics as tutorial for etching, this was my first ever etch and worked well, one tip place the box (or pcb board) onto a hard surface instead of a soft ironing board.
this is a short video i made of the PT-80 delay being used, it gives an idea of the sound capable of this pedal.
This is my PT-80 delay the information for this build can be found on generalguitargadgets.com.
I used acid graphics as tutorial for etching, this was my first ever etch and worked well, one tip place the box (or pcb board) onto a hard surface instead of a soft ironing board.
 pcb after etching (tip: nail polish remover seems to work great for removing pcb paper and pens.) |
 the case side mask with spray paint | |
 full mask, using press'n'peel pcb paper and black enamel paint touch up (TIP: ironing pcb paper seems to work best if the box or board is placed on a hard surface, some scrap wood is ideal.) |
 box etching | |
 after the etchant was washed off |
 the final pedal | |
 inside the final pedal |
this is a short video i made of the PT-80 delay being used, it gives an idea of the sound capable of this pedal.
